        Description

        UNI-T Digital Multimeters UT81B handheld digital multimeters have embedded digital control technology design, which combines with digital storage oscilloscopes, digital multimeters, etc. The oscilloscope mode test is a complete intelligent measurement system, when testing DC voltage, current, and frequency, the test waveform can be easily observed by switching to the oscilloscope. Waveform test bandwidth is 2MHz to provide sufficient bandwidth for various measurements, 20MS/s constant sampling rate with peak sampling can catch industrial signals, such as spikes and lost pulses.

        Specifications of Digital Multimeters UT81B

        Specifications Range UT81B
        DMM Specifications
        DC voltage (V) 1000V ±(0.8% 8)
        AC voltage (V) 750V ±(1% 15)
        DC current (A) 10A ±(1% 8)
        AC current (A) 10A ±(1.5% 8)
        Resistance (Ω) 40MΩ ±(1% 5)
        Capacitance (F) 100μF ±(3% 8)
        Frequency (Hz) 10Hz~10MHz ±(0.1% 3)
        Scope Specifications
        Bandwidth 8MHz
        Sampling rate 40MS/s
        Vertical accuracy ±(5% 1)
        Vertical sensitivity 20mV/div~500V/div (1-2-5)
        Time-base accuracy ±(0.01% 1)
        Time-base range  100ns/div -5s/div (1-2-5)
        Features
        Display count 4000
        Auto range
        Duty cycle 0.1~99.9%
        Diode
        Auto power off
        Continuity buzzer
        Display 160 x 160 monochrome
        Trigger types Autorun/Normal/Single shot
        Memory 10 screens and setups
        Contrast and brightness setup
        Low battery indication
        USB interface
        LCD backlight
        Input impedance for DCV Around 10MΩ
        General Characteristics
        Power 1.5V battery (R6) x 4
        Display 60mm x 60mm
        Product Color Red and grey
        Product net weight 498g
        Product size 200mm x 100mm x 48mm
        Standard accessories Batteries, test lead, alligator clip, USB interface cable, PC software CD
        Standard individual packing Gift box, English manual
        Standard quantity per carton 12pcs
        Standard carton measurement 485mm x 450mm x 260mm (0.057CBM per standard carton)
        Standard carton gross weight 23kg
        Optional accessories Scope probe, AC power adaptor
