function / arbitrary waveform generator high frequency signal generator
0
৳ 16,500
⚡ Rigol Function / Arbitrary Waveform Generator
Model: DG1022 / DG1022Z / Equivalent
Brand: Rigol Technologies
🧰 Product Overview
The Rigol Function / Arbitrary Waveform Generator is a high-precision signal generator used to produce a wide range of electrical waveforms including sine, square, pulse, ramp, and arbitrary shapes.
It’s ideal for electronics labs, testing environments, calibration facilities, and educational institutions, offering excellent frequency accuracy, amplitude stability, and waveform versatility.
With its advanced digital synthesis (DDS) technology, this Rigol generator ensures low distortion and high signal fidelity, perfect for research, development, and circuit testing.
⚙️ Key Features
-
✅ Dual-channel output with independent control.
-
✅ Frequency Range: Up to 25 MHz (depending on model).
-
✅ High-accuracy DDS technology for stable output.
-
✅ Waveform Types: Sine, Square, Triangle, Pulse, Noise, DC, Arbitrary.
-
✅ Sampling Rate: Up to 125 MSa/s.
-
✅ Amplitude Range: 1 mV to 10 Vpp (50 Ω load).
-
✅ High-resolution LCD display for easy waveform visualization.
-
✅ USB and LAN interface for PC connectivity.
-
✅ Compact, lightweight, and user-friendly design.
📏 Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Rigol DG1022 / DG1022Z / Equivalent |
| Channels | 2 Independent Outputs |
| Frequency Range | 1 µHz – 25 MHz |
| Sampling Rate | 125 MSa/s |
| Vertical Resolution | 14 bits |
| Waveforms | Sine, Square, Ramp, Pulse, Noise, Arbitrary |
| Max Amplitude | 10 Vpp (into 50 Ω load) |
| Output Impedance | 50 Ω |
| Modulation Modes | AM, FM, PM, PWM, FSK |
| Display | 3.5” TFT Color LCD |
| Interface | USB Device, LAN (optional) |
| Power Supply | 220V AC, 50/60 Hz |
| Brand | Rigol |
| Country of Origin | China |
🧪 Applications
-
Electronic circuit testing
-
R&D and academic laboratories
-
Calibration and maintenance centers
-
Component characterization
-
Industrial electronics and signal simulation
💡 Benefits
-
Generates multiple signal types with precision.
-
High reliability and low harmonic distortion.
-
Easy operation through intuitive interface.
-
Perfect for lab, education, and professional testing.
-
Long service life with minimal maintenance.
📞 Order Now
Rahim Trading Corporation (RTC Dhaka)
📍 Swantex Bhaban, 9/I Motijheel C/A, Dhaka – 1000
📱 +8801831-016720
📧 rtcdhaka2013@gmail.com
🌐 www.rtcdhaka.com
